The CRH is the perfect complement for Edgebanders with no corner rounding feature. The automatic hydropneumatic copying system the of the CRH executes perfect rounding of sharp and shaped corners on already edged panels. The CRH copy corner rounder does its job with the panels held well in position. The corner rounding made by the CRH is comparable to those found on large and complex machines.
- Rounds corners in only a few seconds
- Follows all types of shapes and corners
- Eliminates the follow-up system cut
- Rounds kitchen top corner
| Panel thickness |
min-max 10 - 50 mm |
| Edge thickness to be trimmed off |
min-max 0,4 - 3,0 mm |
| Pneumatic trimming motor |
0,37 KW 24.000 RPM (compressed air 6,5 Bar) |
| Cutterhead |
shaft Ø 6 mm - Z2 R=1 mm - Z2 R=2 mm |
| Dust collection outlet |
Ø 100 mm |
